Epoxy Resin EPIKOTE™ L 20 + EPIKURE™ Curing Agent 141
Epoxy Resin EPIKOTE™ L 20 + EPIKURE™ Curing Agent 141

set of 2 components:
675 g, 1.35 kg and 2.7 kg

Kostenloser Harzrechner Resin Calculator

Kostenloser Laminatrechner Laminate calculator

Comparative data for epoxy resin systems

Westlake
more products by westlake

Epoxy Resin EPIKOTE™ L 20 + EPIKURE™ Curing Agent 141

Set of 2 components

Assortment adjustment. This discontinued item is qualitatively perfect goods without defects. Sale while stocks last.

  • Low viscosity (600-800 mPa-s, at 25 °C)
  • Solvent-free
  • Alkylphenol-, bisphenol A-free
  • Fast curing even at low temperatures
  • Good mechanical properties
  • Good surface quality
  • Accelerator for less reactive hardeners

Epoxy resin EPIKOTE™ Resin L 20 + Hardener EPIKURE™ Curing Agent 141

Low viscosity, cold-curing epoxy resin system with excellent impregnation and wetting properties for glass, aramid and carbon fibres.

Application:
The system is suitable for hand laminates. The high reactivity of the resin system enables a short dwell time in the mould, especially for difficult laminates and sandwich structures. The system is frequently used in glider and boat construction.

Processing:

Processing time at 25 °C (100 g in a cup): 20 - 25 minutes

Mixing ratio:
100 : 35 parts by weight epoxy resin EPIKOTE™ Resin L 20 : hardener EPIKURE™ Curing Agent 141

Technical data:

Physical properties (at the time of manufacture):

  EPIKOTE™
Resin L20		 EPIKURE™ Curing Agent 141
Viscosity at 25 °C in mPa*s 900 ± 150 600 - 800
Density at 20 °C in g/cm³ 1.15 ± 0.01 -
Colour (Gardner) < 3 max. 9
Epoxy equivalent weight in g/equiv. 175.5 ± 3.5 -
Amine equivalent weight in g/equiv.   60
Amin number in mg KOH/g  - 460 - 500
Refractive index at 25 °C 1.5495 ± 0.0030
Potlife at 25 °C (100 g in a cup) in min 20 - 25
westlake

Epoxy Resin EPIKOTE™ L 20 + hardener EPIKURE™ Curing Agent 141 (25 min.) kit/ 675 g

(500 g resin + 175 g hardener)

Item no.  1121091 Only 4 left in stock  (delivery time 1-2 days)

Add to Shopping List

15,33 €
22,88 €
(Base Price 22,71 € /  kg)
- +
westlake

Epoxy Resin EPIKOTE™ L 20 + EPIKURE™ Curing Agent 141 (25 min.) kit/ 1.35 kg

(1 kg resin + 350 g hardener)

Item no.  1121092 Only 4 left in stock  (delivery time 1-2 days)

Add to Shopping List

28,27 €
42,20 €
(Base Price 20,94 € /  kg)
- +
westlake

Epoxy Resin EPIKOTE™ L 20 + EPIKURE™ Curing Agent 141 (25 min.) kit/ 2.7 kg

(2 kg resin + 700 g hardener)

Item no.  1121093 Only 2 left in stock  (delivery time 1-2 days)

Add to Shopping List

50,37 €
75,17 €
(Base Price 18,66 € /  kg)
- +

all Prices  price incl. VAT, possibly plus shipping

Article information

type: ga
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]
Instructions for use
type: si
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]
MSDS
MSDS Epoxy resin EPIKOTE™ Resin L 20 (PDF)
MSDS Härter EPIKURE™ Curing Agent 141 (PDF)
type: pi
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]
Product information
type: td
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]
Processing information Epoxy resin systems (PDF)
Technical Data Sheet Epoxy resin EPIKOTE™ Resin L 20 + Hardeners (PDF)
Technical Data Sheet Hardener EPIKURE™ Curing Agent 141 (PDF)
type:
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]

Hazards identification - Hardener EPIKURE™ Curing Agent 111

Hazard components for labelling

Formaldehyde, polymer with N-(2-aminoethyl)-1,2-ethanediamineand phenol
2,2'-iminodiethylamine
Phenol

Signal word: Danger

Pictograms:

GHS05 GHS07 GHS09

Hazard statements

H314 Causes severe skin burns and eye damage.
H317 May cause an allergic skin reaction.
H410 Very toxic to aquatic life with long lasting effects.

Precautionary statements

P261 Avoid breathing dust/fume/gas/mist/vapours/spray.
P273 Avoid release to the environment.
P280 Wear protective gloves / protective clothing / eye protection / face protection.
P301 P330 P331 IF SWALLOWED: Rinse mouth. Do NOT induce vomiting.
P305 P351 P338 IF IN EYES: Rinse continuously with water for several minutes. Remove contact lenses if present and easy to do. Continue rinsing.
P310 Immediately call a POISON CENTER or doctor / physician.
P362 P364 Take off contaminated clothing and wash it before reuse.
P405 Store locked up.
P501 Dispose of waste according to applicable legislation.

Hazards identification - Epoxy Resin EPIKOTE™ Resin L 20

Hazard components for labelling

reaction product: bisphenol-A-(epichlorhydrin)
epoxy resin (number average molecular weight <= 700)

Signal word: Warning

Pictograms:

GHS07 GHS09

Hazard statements

H315 Causes skin irritation.
H317 May cause an allergic skin reaction.
H319 Causes serious eye irritation.
H411 Toxic to aquatic life with long lasting effects.

Precautionary statements

P261 Avoid breathing dust/fume/gas/mist/vapours/spray.
P264 Wash hands thoroughly after handling.
P273 Avoid release to the environment.
P280 Wear protective gloves / protective clothing / eye protection / face protection.
P305 P351 P338 IF IN EYES: Rinse continuously with water for several minutes. Remove contact lenses if present and easy to do. Continue rinsing.
P333 P313 If skin irritation or a rash occurs: Get medical advice / attention.
P337 P313 If eye irritation persists: Get medical advice / attention.
P362 P364 Take off contaminated clothing and wash it before reuse.
P391 Collect spillage.

Special labelling of certain mixtures

EUH205 Contains epoxy constituents. May produce an allergic reaction.
